Mercedes Heavy Duty Hub Brake Discs

Key Features & Specifications

1. Robust Construction:

• Material: Constructed from high-quality G3000 cast iron (equivalent to GG25/HT250) with ≥95% pearlite content, ensuring superior wear resistance and structural integrity.

• Vented Design: Internally ventilated (e.g., 430mm diameter, 45mm thickness) with optimized vanes for efficient heat dissipation, reducing brake fade during prolonged use.

• Hub Integration: Directly compatible with Mercedes-Benz truck axles, featuring precise centering diameters (e.g., 211mm) and bolt patterns (e.g., 10 holes, 238mm pitch circle diameter) for secure, vibration-free installation.

2. Performance & Compliance:

• ECE R90 Certification: Meets stringent European safety standards for braking efficiency, thermal stability, and corrosion resistance, ensuring roadworthiness across global markets.

• Longevity: Engineered for extended service life, with real-world applications showcasing up to 400,000 km of wear resistance when paired with Mercedes-Benz’s advanced braking systems (e.g., Actros MP4 models).

• Thermal Management: Vented design and heat-resistant materials enable consistent performance even at temperatures exceeding 500°C, critical for heavy-duty operationsspecial.mercedes-benz-trucks.com.

3. System Compatibility:

• Integration with Safety Systems: Works seamlessly with Mercedes-Benz Trucks’ ABS, ESP, and adaptive braking technologies, ensuring balanced stopping power and stability.

• Hybrid & Electric Compatibility: Optimized for use in hybrid and electric truck variants (e.g., Econic NGT), complementing regenerative braking systems.

4. OEM Quality & Reliability:

• Genuine Parts Assurance: Manufactured to Mercedes-Benz’s exact OE specifications, ensuring perfect fitment and compatibility with factory calipers, pads, and hardwarehub.mercedes-benz-trucks.com.

• Warranty: Backed by Mercedes-Benz Trucks’ global warranty, offering peace of mind for fleet operators and owner-drivershub.mercedes-benz-trucks.com.

Applications

• Actros: Long-haul trucks, construction vehicles, and heavy-duty tractors.

• Atego: Light to medium-duty distribution trucks.

• Unimog: All-terrain workhorses for off-road and industrial applications.

• Econic: Urban delivery trucks and specialized municipal vehicles.

Benefits for Fleet Operators

1. Reduced Downtime: Extended service life minimizes replacement frequency, lowering maintenance costs and operational interruptions.

2. Enhanced Safety: ECE R90 compliance and thermal stability reduce the risk of brake failure in critical situations.

3. Fuel Efficiency: Lightweight design (e.g., 23.9 kg for 377mm discs) and optimized heat dissipation contribute to lower energy consumption.

4. Total Cost of Ownership (TCO): Durability and OE compatibility align with Mercedes-Benz’s TCO philosophy, maximizing long-term value.

Overview

This product is a heavy‑duty brake disc engineered specifically for Mercedes‑Benz commercial and heavy‑duty vehicles, featuring an integrated hub assembly that simplifies installation and ensures precise fitment. Designed for applications that demand exceptional durability and braking performance—including Sprinter vans, G‑Class off‑road vehicles, Actros and Atego trucks, and other Mercedes heavy platforms—this disc delivers reliable stopping power under sustained heavy loads, frequent braking, and demanding operating conditions. The integrated hub design eliminates the need for separate hub and bearing assembly, reducing installation time and ensuring correct preload and concentricity. Available with ventilated construction, multiple protective finishes, and performance configurations, this disc offers fleet operators, commercial workshops, and heavy‑duty vehicle owners a durable, cost‑effective braking solution that meets the rigorous demands of commercial and off‑road use.

The Heavy‑Duty Distinction – Why Ordinary Discs Are Not Enough

The Unique Demands of Heavy‑Duty Applications

• Mercedes commercial vehicles operate under conditions that far exceed those of standard passenger cars.

• Higher vehicle weights—fully loaded vans, trucks, and SUVs generate significantly greater kinetic energy during braking.

• Sustained braking events—mountain descents, urban stop‑and‑go traffic, and repetitive braking cycles.

• Harsh operating environments—mud, water, debris, temperature extremes, and road salt.

• Extended service intervals—commercial vehicles are often expected to operate with minimal downtime.

What a Heavy‑Duty Brake Disc Must Deliver

• Thermal capacity – The ability to absorb and dissipate heat without fade or distortion.

• Structural strength – Resistance to cracking, warping, and premature wear under heavy loads.

• Corrosion resistance – Protection against the contaminants and moisture encountered in commercial and off‑road use.

• Serviceability – Simplified installation and maintenance to minimise vehicle downtime.

Hub Brake Disc – The Integrated Assembly Advantage

What Is a Hub Brake Disc?

• The hub brake disc configuration means the disc and wheel hub are supplied as a single, pre‑assembled unit.

• The hub includes the wheel bearing, pre‑set with correct preload and concentricity at the factory.

• The disc is mounted on the hub, ready for direct installation onto the vehicle.

The Value of Integrated Assembly for Heavy‑Duty Vehicles

Simplified Installation

• The disc and hub are assembled as one unit—no pressing, no bearing adjustment, no complex assembly procedures.

• Installation is significantly faster than assembling separate disc, hub, and bearing components.

• For commercial workshops, this reduces labour time and improves bay utilisation.

Correct Preload and Concentricity

• The bearing preload is set at the factory to the manufacturer's exact specifications.

• Concentricity between the disc and hub is guaranteed—critical for minimising run‑out and pedal pulsation.

• This precision reduces the risk of vibration, uneven pad wear, and premature bearing failure.

Reduced Parts Complexity

• One part number covers the complete assembly—simpler ordering, reduced inventory complexity.

• Fewer individual components to stock and manage.

• Reduced risk of ordering incorrect or incompatible parts.

Serviceability

• The integrated assembly allows for complete axle‑end replacement in a single operation.

• Bearing and disc wear often occur on similar timelines—replacing both simultaneously ensures comprehensive service.

• For fleet operators, this means predictable maintenance schedules and reduced downtime.

Ventilated Construction – Thermal Management for Heavy Loads

• Internal cooling vanes between the two friction faces promote airflow and dissipate heat.

• For heavy‑duty vehicles with higher gross vehicle weights, ventilation is not optional—it is essential.

• The ventilated design reduces brake fade during sustained braking events—long descents, heavy loads, and repetitive stops.

• Effective heat dissipation also extends pad and disc life in demanding conditions.

• The ventilated construction works in combination with the disc's mass and material to provide the thermal capacity required for heavy‑duty applications.

Performance Design Options – Tailoring to Application

Standard Ventilated

• The standard configuration—ventilated disc with smooth friction surface.

• Suitable for most heavy‑duty applications where consistent, reliable braking is the primary requirement.

• Provides excellent durability and thermal management.

Grooved Configuration

• Grooves across the friction surface provide self‑cleaning action.

• Removes mud, dust, and debris from the pad‑disc interface.

• Prevents pad glazing and maintains consistent friction.

• Particularly valuable for off‑road and construction applications.

Drilled Configuration

• Holes across the friction surface enhance heat dissipation and water evacuation.

• Reduces gas build‑up between pad and disc.

• Improves wet‑weather braking response.

• Suitable for applications where water and mud exposure is frequent.

Drilled + Grooved Combination

• Combines cooling, cleaning, and bite for maximum performance.

• Recommended for the most demanding heavy‑duty applications.

Surface Protection Options – Heavy‑Duty Finishes

Oiled

• Light rust‑preventive oil film applied during production.

• Protects during storage and transit.

• Suitable for indoor storage and controlled environments.

Painted

• Durable paint applied to the hub and outer edges.

• Provides long‑term corrosion resistance.

• Recommended for regions with high humidity, coastal environments, or winter road salt exposure.

• Particularly valuable for vehicles operating in harsh climates.

Coated

• Advanced anti‑corrosion coating (zinc or geometric) offering superior long‑term protection.

• Gradually wears from the friction area during normal braking.

• The highest level of corrosion protection—ideal for off‑road, construction, and heavy‑duty applications.

• Recommended for vehicles exposed to mud, water, salt, and debris.

Who Is This Product For?

Mercedes Sprinter Owners and Operators

• For owners and operators of Mercedes Sprinter vans—used for cargo transport, passenger shuttles, camper conversions, and commercial fleets.

• The integrated hub design simplifies maintenance for high‑mileage vehicles.

• The heavy‑duty construction provides the durability required for commercial use.

Mercedes G‑Class and Off‑Road Owners

• For G‑Class owners who use their vehicles off‑road—on trails, through water crossings, over rocks and mud.

• The heavy‑duty construction and optional grooved/drilled configurations provide the durability and self‑cleaning needed for off‑road conditions.

• The corrosion‑resistant finishes protect against mud, water, and debris.

Commercial Fleet Operators

• For businesses operating Mercedes commercial vehicles in their fleets—delivery vans, service vehicles, emergency vehicles, and utility fleets.

• The integrated hub assembly reduces maintenance time and downtime.

• The durable construction reduces replacement frequency and total operating costs.

Mercedes Heavy‑Duty Truck Operators

• For owners and operators of Mercedes Actros, Atego, and other heavy truck platforms.

• The ventilated design provides the thermal capacity required for heavy loads and long hauls.

• The integrated hub design simplifies service and reduces complexity.

Camper and RV Conversion Specialists

• For specialists converting Mercedes Sprinter vans into campervans and RVs.

• The additional weight of conversions increases braking demands—heavy‑duty discs provide the required capacity.

• The integrated hub design simplifies installation during the conversion process.

Workshops Specialising in Commercial Vehicles

• For service centres that work on Mercedes commercial vehicles—Sprinter, G‑Class, trucks, and vans.

• The integrated hub assembly simplifies service and reduces labour time.

• The heavy‑duty construction provides a premium option to recommend to commercial customers.

The Integrated Hub Advantage – A Cost‑Benefit Perspective

For Workshop Operators

• Reduced installation time—more vehicles serviced per bay.

• Simplified ordering—one part number, one assembly.

• Reduced risk of installation errors—pre‑set bearing preload and concentricity.

• Fewer customer comebacks—correct installation ensures reliable performance.

For Fleet Operators

• Predictable maintenance—the integrated assembly simplifies service planning.

• Reduced downtime—faster installation means vehicles return to service sooner.

• Lower total cost of ownership—durable construction reduces replacement frequency.

• Simplified parts inventory—one assembly covers the complete hub and disc requirement.

Quality Assurance and Manufacturing Standards

• Manufactured to Mercedes heavy‑duty OEM specifications for fitment and compatibility.

• Hub assembly with factory‑set bearing preload and concentricity.

• Dimensional accuracy verified—run‑out and thickness variation controlled to tight tolerances.

• Ventilation vane structure checked for casting integrity.

• Surface finish controlled for proper pad bedding and consistent friction.

• Corrosion resistance of surface finishes validated through standardised testing.

• Heavy‑duty grade materials and construction—designed for commercial application longevity.

Fitment and Compatibility

• Designed for Mercedes‑Benz heavy‑duty applications—Sprinter, G‑Class, Actros, Atego, and other commercial platforms.

• Integrated hub assembly—disc and hub supplied as a complete unit.

• Ventilated construction with optional grooved and/or drilled configurations.

• Available in various sizes to cover different Mercedes heavy platforms.

• Direct replacement—no modifications required.

• Consult the product catalogue or contact Winhere with vehicle details for specific fitment confirmation.

• 100% critical dimensions, runout and DTV inspection

• Material physical and chemical inspection

• Test shear strength, compressibility, density, flatness and parallelism

• Test performance and noise/NVH
